Security Cable 22 AWG 4c Stranded Copper Control Cable
Hangzhou Risun Cable Co., Ltd.- Application：Local Communication Cable, LAN Cable, Alarm Cable Security Cable
- Conductor Material：Copper
- Cover Material：PVC
- Material Shape：Round Wire
- Conductor Type：Stranded
- Certification：CE, ISO, RoHS, CCC, ETL,CPR
Base Info
- Brand：Risun or OEM
- Insulation：PVC
- Sheath：PVC
- Shield：Unshield
- Transport Package：100m,Coil, 305m,Relex Box, 500m,Wooden Drum
- Origin：Hangzhou, Zhejiang, China
- HS Code：8544491100
- Production Capacity：20000 Boxes , Month
Description
SheathMaterial : PVC
Electrical Properties
Mechanical Properties
Package
100m/coil,305m/relex box,500m/wooden drum or according to your request
Company Profile
Hangzhou Risun Cable Co.,Ltd is a professional manufacturer and exporter of LAN CABLE, ALARM CABLE,TELEPHONE WIRE and COAXIAL CABLE in China since year of 2007.
More than 90% of our products for export market. We are an ISO certified company and our products approved by CE, RoHS, ETL, CPR. Our main products include CAT5E, CAT6,CAT6A, cat7, multiple cores (pairs) of alarm cable and telephone cable, audio cable, Jumper wire,KNX cable, RG59, RG6, RG11, RG58/U, KX6, RG213 etc.
Our brand is RISUN, and we also accept OEM serivce. As a professional manufacturer and exporter,we can provide the extra savings to our customers with the best quality to help our customers grow their business and market shares.
process of production
Electrical Properties
| Voltage Rating | ELV |
| Max. Conductor DC Resistance @ 20°C | 93.3Ω/km |
| Min. Insulation Resistance @ 20°C | 50MΩ.km |
| Voltage Test: Conductor to core | 1.5 kV ac/1min |
| Voltage Test: Core to sheath | 3.0 kV ac/1min |
Mechanical Properties
| Operating Temperature Range | -15 to 70ºC |
| Max. Recommended Pulling Tension | 56N |
| Min. Bend Radius (install) | 36mm |
| Approximate Mass | 1.92kg/100m |
Package
100m/coil,305m/relex box,500m/wooden drum or according to your request
