• Model NO.：MV Cu(Al)XLPE,PVC
• Wire Core Material：Copper , Aluminum
• Certification：ISO, CCC
• Model：Mv Cu(Al)XLPE,PVC
• Brand：Hongda
• Armour Material：Swa , Sta , Awa ,ATA
• Warranty：One Year
• Transport Package：Wooden Drum, Steel & Wooden Drum
• Specification：Single core, 3 cores, 25~630sqmm
• Trademark：Hongda
• Origin：China
• HS Code：8544601200
• Production Capacity：1000km,Month

Chinese TypeDescriptionApplicationCuAlYJVYJLVCu conductor(Al conductor)XLPE insulated PVC sheathed power cableLaying indoors, in tunnel, fixed on the bracket, pipe and buried in the soil, the cable can not bear external mechanical forces.YJYYJLYCu conductor(Al conductor)XLPE insulated PE sheathed power cableYJV22YJLV22Cu conductor(Al conductor)XLPE insulated double of steel-tape armored PVC sheathed power cableFor laying indoors, in tunnel, cable trench, or direct in ground, able to bear external mechanical forces, but unable to bear large pulling force.YJV23YJLV23Cu conductor(Al conductor)XLPE insulated double of steel-tape armored PE sheathed power cableYJV62YJLV62Cu conductor(Al conductor)XLPE insulated double of aluminium-tape armored PVC sheathed power cableYJV32YJLV32Cu conductor(Al conductor)XLPE insulated steel-wire armored PVC sheathed power cableFor laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling forceYJV33YJLV33Cu conductor(Al conductor)XLPE insulated steel-wire armored PE sheathed power cableYJV72YJLV72Cu conductor(Al conductor)XLPE insulated  aluminium-wire armored PE sheathed power cableNote: KAIQI POWER can produce "Flame-Retardant Series", "Fire-Resistant Series", "Low Smoke Halogen Free
(LSHF/LSOH) Series","Low Smoke Low Halogen (LSLH) Series", etc. power cable as customer required.
Performance in line with IEC60332,IEC 61034,IEC60754 requirements.

4.Production Range
   Rated Voltage U0/U(Um) (kV) : 3.6/6(7.2), 6/6(7.2) ,6/10(12.0), 8.7/10(12)   8.7/15(17.5),12/20(24.0),18/30(36.0),21/35(40.5),26/35(40.5) No. of cores : 1 , 3, Nominal cross-section(mm2): 25~630
5.Construction
   Conductor: Plain annealed stranded compacted circular copper or aluminium conductor to IEC60228 class 2
   Conductor Screen:Extruded semi-conductive compound
   Insulation:XLPE (cross-linked polyethylene) rated at 90°C
   Insulaton Screen:Extruded semi-conductive compound
   Metallic Screen:copper tape or a concentric layer of copper wires
   Colour for core indentification:Red,Yellow ,Blue tape shall be applied between insulation screen and metallic screen
( The above identifying can be changed as order)
   Assembly : Three screened cores are laid up together ,if necessary filled with non hygroscopic material compatible
with insulation and covered with a layer of PVC sheath
   Inner Sheath:Extruded layer of PVC ST2 or PE , LSZH
   Armour: Double of galvanized steel tape or galvanized steel wire for three core power cable ,Double of aluminium tape or aluminium wire for single power cable
   Outer Sheath: PVC type ST2 to IEC 60502 or PE ,LSZH
