• Model NO.：HFP56
• Certification：ISO, CE
• Model：Hfp56
• Shell：Aluminum Alloy Shell
• Pipe：PVC
• Inside：Copper Bar
• Busway Character：Flame Retardant
• Trademark：NANTE
• Origin：China

Basic Info.

Model NO. HFP56 Certification ISO, CE Model Hfp56 Shell Aluminum Alloy Shell Pipe PVC Inside Copper Bar Busway Character Flame Retardant Trademark NANTE Origin China

Product Description

Introduction



The ranges of applications of HFP Power Rail Enclosed Conductor System

1. Overhead and elongated tracks for cranes.
2. Electric hoists, electric tools, stacking systems.
3. Electric tools
4. Other applications for supplying power to moving power load.

 Design features



 Compact arrangement, corrosion resistance and simple assembly are its essential features.



Housing

Color green, PVC housing for 4 conductors. Standard section 4 m.

Other sections are available.

The ground conductor is identified by international color code.

Phase reversing prevented by design of the collector and housing.



Current collectors

The current collectors are made of re-inforced polyester fiberglass,for high strength and light weight.

Spring loaded carbon brushes maintain uniform contact.

Connecting cables and hinged or flexible towing arms included.

Double Current collectors for transfer applications and higher amperage.


Model	Pole No.	Cross section (mm2 )	Max. current (A)	Leakage-distance (mm)	Max. voltage (V)	Resistance (Ω)	Weight (kg)
HFP56-4-8/35	4	8	35	35	600	1.944	2.09
HFP56-4-10/50	4	10	50	35	600	1.656	2.16
HFP56-4-12/65	4	12	65	35	600	1.321	2.23
HFP56-4-15/80	4	15	80	35	600	1.137	2.3
HFP56-4-20/100	4	20	100	33	600	1.011	2.43
HFP56-4-25/120	4	25	120	33	600	0.713	2.56
HFP56-4-35/140	4	35	140	33	600	0.522	2.95
HFP56-4-50/170	4	50	170	33	600	0.337	3.25
HFP56-4-70/210	4	70	210	33	600	0.265	3.85
HFP56-4-80/240	4	80	240	30	600	0.223	4.16
