• Model NO.：0361TQ
• Wire Core Material：Extra Fine Bare,Tinned Copper Strands
• Certification：ISO, CCC, CE, RoHS, UL, VDE
• Model：0361tq
• Brand：Feiya
• Temperature Range：-25 Degree to +85 Degree
• OEM&ODM：Yes
• Rated Voltage：100V
• Operating Environment：Domestic Premises, Such as Kitchens and Offices
• Other Service：Can Be Customized
• Colors：Can Be Customized
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：BS 6360 CL-6, or CL-5 (120mm and above)
• Trademark：Feiya
• Origin：China
• HS Code：8544
• Production Capacity：80000 Meter,Meters Per Month

AWG(No of Strands/Strand Diameter)

No. of Cores x         Nominal Cross        Sectional Area

Nominal

Thickness of Insulation

Nominal

Thickness of Sheath

Nominal Overall Diameter

Nominal   Cable Weight

No. x mm²

mm

mm

mm

kg/km

6(903/35)

1×16

1.2

2

11.0±0.5

230

4(1407/35)

1×25

1.4

2

12.5±0.5

325

2(1974/35)

1×35

1.4

2

14±0.5

440

1(2830/35)

1×50

1.6

2.2

16.5±0.5

600

2/0(3952/35)

1×70

1.6

2.4

18.5±0.5

830

3/0(5370/35)

1×95

1.8

2.6

21.0±0.5

1110

4/0(614/24)

1×120

1.8

2.8

23.5±0.5

1375

300MCM(765/24)

1×150

2

3

26±0.5

1680

350MCM(944/24)

1×185

2.2

3.2

27.5±0.5

2050

500MCM(1225/24)

1×240

2.4

3.2

30.5±0.5

2630
