155 Class Polyester Enameled Wire QZ-1/155 Thread

Shanghai Tankii Alloy Material Co., Ltd.
  • Insulation Level：F
  • Certification：ISO9001, UL
  • Brand：-
  • Shape：Round Wire
  • Conductor Material：-
  • Than bending：20.5

Base Info

  • Model NO.：QZ-1,155
  • resistivity：0.21
  • density：8.03G,cm³
  • Allows the use of temperature：-70~260
  • Modulus of elasticity：1.38
  • use：Thermal protector
  • Linear temperature：-20~200
  • Temperature curvature：38.7%±5%
  • Transport Package：Plywood Case
  • Specification：negotiable
  • Trademark：tankii
  • Origin：China
  • HS Code：7408229000
  • Production Capacity：3000 Tons,Year

Description

Insulation-enamelled Name

Thermal LevelºC

(working time 2000h)

Code Name

GB Code

ANSI. TYPE

Polyurethane enamelled wire

130

UEW

QA

MW75C

Polyester enamelled wire

155

PEW

QZ

MW5C

Polyester-imide enamelled wire

180

EIW

QZY

MW30C

Polyester-imide and polyamide-imide double coated enameled wire

200

EIWH

(DFWF)

QZY/XY

MW35C

Polyamide-imide enamelled wire

220

AIW

QXY

MW81C
