Sat50 M Coaxial Cable
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：RG6 Cable
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：SAT50
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Brand：OEM
- Cable Conductor：1.02mm
- Transport Package：Roll,Wooden Spool,Plastic Reel,Gift Box,Pully Box
- Trademark：FUU
- Origin：Made in China
- HS Code：8544200000
- Production Capacity：3000km,Month
Description
Construction Parameters: Inner Conductor 1.00mm±0.02mm Copper Dielectric 4.75mm±0.10 Foamed PE Shield 1 AL/PET Shield 2 CuSn braid wire 38% coverage Outer sheath 6.60±0.10mm PVC *Notes AL/PET= Aluminium/Polyester Electrical Characteristics: Inner Conductor Resistance 17.5Ω/KM Capacitance 54 ±3 pF/m Impedance 75 ± 3 Ω Return loss between 5 and 1000MHz: > 22dB Velocity of Propagation 0.85 Sparker Test (VAC) 4 Attenuation(20ºC): Frequency (MHZ) Max Attenuation (dB/100m) 5 2.00 10 2.80 30 3.80 50 4.60 200 8.60 300 10.50 470 13.60 862 18.80 1000 20.40 1750 27.80 2150 31.10 2400 33.30 3000 37.70 Mechanical and Envrionmental Properties Cable bend radius 10 times the cable diameter Operating Temp Range -20 ºC to 60ºC Cable diamensions 6.6±0.15mm PVC Order Informations: Marking SAT50 M COAXIAL CABLE ×××M Package 100M/Reel (Per customers inquire) Delivery time Normally 25 days after received the deposit.
