• Model NO.：RG59U
• Certification：CE, ISO, RoHS, UL
• Inner Coductor：CCS,Cu
• Inner Coductor Od：0.81mm
• Dielectric Od：3.66
• Dielecric：Foam PE
• 1st Shield：Al Foil
• 2ND Shield：Al,CCA Bradis
• Shield Covery：30%-90%
• Jacket：PVC
• Jacket Od：6.0mm
• Usage：CCTV,CATV
• Transport Package：100m,Roll, 6rolls,CTN, 305m,Wooden Drum,CTN
• Specification：CE. ROHS. ETL, ISO
• Trademark：OEM or HF
• Origin：Lin′an Zhejiang
• HS Code：854420000
• Production Capacity：2000000m,Year

ConductorMaterialBC/CCSNom.Dia.0.81mmDielectricMaterialFoam PENom.Dia.3.66mmShieldMaterialAl foil+Al braidingCoverage40%-95%JacketMaterialPVC/PENom.Thick.0.80mmNom.Dia.6.10mm

BASIC CHARACTERISTICS

Nominal Impedance(ohm)75±3 Nominal Velocity of Propagation(%)85 Nominal Capacitance(pF/m)50 Sparker Test(VAC)4000 SRL(dB)2020Attenuation(68°F(20°C))        Frequency(MHz)Maximum(dB/100ft)Maximum(dB/100m)50.862.82552.056.731873.611.813004.4514.64505.417.726006.220.347506.9722.878657.5224.6710008.1226.64


Packing:
1) Packing Lengths:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's request;
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull out box, pallet available.
4) Other packing available according to client's request.

#Coaxial Cables:
1) RG series Coaxial Cable: rg59, rg6, rg7, rg8, rg11, RG58, rg142, rg174, rg178,rg213, rg214, RG316,etc;
2) JIS series Coaxial Cable: 1.5C-2V, 2.5C-2V, 3C-2V, 3C-2VR, 4C-2V, 5C-2V, 7C-2V, 10C-2V, 3D-2V, 5D-2V, 8D-2V, 10D-2V, etc;
3) Vatc series Coaxial Cable:17vatc, 19vatc, 21vatc, 25vatc, kx6a, kx8;
4) TRUNK Cable: P3 412, 500, 540, 625, 750, 860 ;
5) LMR SERIES: LMR195,LMR200, LMR400, LMR600 ;
6) Network Cables: Lan Cable CAT3, Lan Cable CAT5, Lan Cable CAT5e, Lan Cable CAT6, Lan Cable CAT7;
7) Combined Cable: Siamese Cables: RG59+2C, RG6+lan cable .
Note:If the specification is not you need,please tell me and i will offer you price according your requirements.
