Jaso Standard Aex Bare Copper Conductor 0.5 0.75 0.85 1.25 mm2 Car Automotive Auto Electric Wire
CB (XIAMEN) INDUSTRIAL CO., LTD.- Type：Insulated
- Conductor Type：Stranded
- Conductor Material：Copper
- Insulation Material：XLPE
- Material Shape：Round Wire
- Certification：ISO9001, RoHS
Base Info
- Model NO.：AEX
- Brand：Bort
- Sample：Free Sample Available
- Packaging：610m,Roll
- Color Available：Any Colors
- Delivery Time for Samples：3-5days
- Delivery Time for Mass Production：7-30days
- Appliance：Internal Wiring of Electronic&Electrical Equipment
- Standard of Production：RoHS & Reach
- Factory Management Standard：ISO9001:2008
- Annual Capacity：300,000kms
- Transport Package：Roll or Spool Packing, Stretch Film Wrapping, Car
- Specification：customize
- Trademark：Bort
- Origin：Zhangzhou
- HS Code：8544491900
- Production Capacity：300000km,Year
Description
ConductorFinished product Maximum Resistance at 20ºC Cross Sectional Area NO.of Cond Insulation Thick. Outside Thick. Weight mm2 No./mm mm mm kg/km Ω/mm 0.5F 20/0.18 0.5 2.0 8.52 38.6 0.5 7/0.32 0.5 2.0 8.93 34.6 0.75F 30/0.18 0.5 2.2 11.43 25.8 0.85 11/0.32 0.5 2.2 12.35 22.0 1.25F 50/0.18 0.6 2.7 18.14 15.5 1.25 16/0.32 0.6 2.7 18.25 15.1 2 26/0.32 0.6 3.1 27.06 9.3 3 41/0.32 0.7 3.8 41.84 5.9 5 65/0.32 0.8 4.6 64.32 3.72 8 50/0.45 0.8 5.3 93.07 2.45 Note: The "F" in the table indicates that the conductor is a soft structure
