High Voltage Al/XLPE 11kv ABC Cable, Malemute

YIFANG ELECTRIC GROUP INC.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Overhead, Underground
  • Conductor Material：Aluminum
  • Sheath Material：PVC
  • Insulation Material：XLPE

Base Info

  • Model NO.：Malemute
  • Material Shape：Round Wire
  • Range of Application：Overhead Power Transmission
  • Certification：ISO9001, CE, UL, CCC, RoHS, VDE
  • Brand：Yifang
  • Size：16mm2,25mm2,35mm2,50mm2,70mm2,95mm2,120mm2,150mm2
  • Insulation：XLPE
  • Shield：Aluminum Tape Shield
  • Sheath：PVC
  • Phase Conductor：Stranded Aluminum Wire
  • Beutral Conductor：Insulated Stranded Steel Wire, AAAC,ACSR
  • Transport Package：Wooden Drum
  • Specification：ISO CE SABS
  • Trademark：Zhengzhou Yifang Cable Co., Ltd.
  • Origin：Henan, China
  • HS Code：8544492100
  • Production Capacity：300km,Month

Description


Code WordPhase conductorBare Neutral MessengerNominal Lay LengthWeight Per 1000ft. (lbs. )Allowable Ampacities+Size
(AWG)StrandingInsul. Thick.
(Mils)Size
(AWG)StrandingRated Strength
(lbs. )inchesXLPPOLYXLPPOLYAAC Neutral-messengerPekingese61456756310.3661618570Collie67456756310.3664648570Dachshund41454788110.36929211590Spaniel47454788110.36969611590Doberman274527135014.88147147150120Malemute1/09601/07199014.88234234205160
