Nyy-O. Copper Conductor, PVC Insulation, PVC Outer Sheath
YIFANG ELECTRIC GROUP INC.- Application：Construction, Overhead, Underground
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：VV
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC
- Model：VV
- Brand：Yifang
- Transport Package：Wooden Drum
- Specification：According to packing length
- Trademark：Yifang
- Origin：China
- HS Code：8544492100
- Production Capacity：1000km Per Month
Description
Basic Info.
Model NO. VV Wire Core Material Bare Copper Wire Certification ISO, CCC Model VV Brand Yifang Transport Package Wooden Drum Specification According to packing length Trademark Yifang Origin China HS Code 8544492100 Production Capacity 1000km Per MonthProduct Description
Copper conductor PVC insulation PVC outer sheath low voltage power cable
1. Reference standard: IEC 60502-1. IEC60228.
2. Application: The cable is applied to fixed installation for rated voltage 0.6/1kv of power transmission and distribution line.
3. Production Scope:
Nominal Cross-section:1.5-1000mm2
Rated Voltage:600/1000V
Cores: 1, 2, 3, 4, 5, 2+1, 3+1, 3+2, 4+1 etc.
Color of insulation: Red, Yellow , Green ,Blue, Black ,yellow/green.
4.Construction:
Conductor: Copper or aluminum
Insulation: PVC or XLPE
Inner sheath (Optional): PVC
Armored (optional):
Galvanized steel wire/Aluminum wire/Galvanized steel tape /Aluminum tape /Aluminum alloy interlocked armor.
Outer Sheath: PVC, PE, or other special requirements
