FTTH Self-Supporting Bow-Type Anti-Rodent Armored Outdoor Drop Fiber Optic Cable
Shenzhen Opelink Technology Co., Ltd.- Application：Communication
- Type：FTTH Fiber Cable
- Connection Structure：Outdoor Drop Cable
- Material Shape：Bow-Type
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：100N<1000N
Base Info
- Model NO.：FTTH Armored Outdoor Drop Fiber Optic Cable
- Core：Multicore
- Certification：RoHS, UL, CE, ISO9001, CCC
- Brand：OEM
- Sheath Material：PE or LSZH
- Fiber Core：G652D, G657A1, etc.
- Fiber Count：1core, 2 Cores, 4 Cores
- Reinforcer：FRP, Steel
- Fiber Jacket：PVC ,LSZH
- Jacked Color：Blue, Orange, Green, White etc.
- Temperature Range：-20~70 Degree
- Transport Package：Carton Box
- Specification：fiber optic drop cable with messenager
- Trademark：Opelink
- Origin：China
- HS Code：85447000
- Production Capacity：50000km,Core
Description
Fiber CountAllowable minimum drawing force of optical cable (N) (kg/km) Static Dynamic Short term Long term Short term Long term 1 (2.0±0.1)x(5.4±0.1) 22±0.5 20 40 2200 1000 600 300 2 (2.0±0.1)X(5.4±0.1) 22±0.5 20 40 2200 1000 600 300 4 (2.0±0.1)X(6.4±0.1) 22±0.5 20 40 2200 1000 600 300
Order Information:
----------------------------------------------------FAQ---------------------------------------------------
Q1. Can I have a sample order for this product? What' MOQ of it?
A: Yes welcome send sample order for test. MOQ is 1 piece.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks.
Q3: What' s the payment term
A: We usually use TT(Telegram Transfer) in advance, Western Union. Other payment method is negotiable.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5: What' s the freight of it?
A: It depends on the order quantity. We have some reliable ship forwarders. We will offer cost effective method for you.
Q6: Do you offer guarantee for the products?A: Yes, we offer 1-2 years warranty according to different products.
Q7: What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.
Order Information:
| Fiber Core | Fiber Type | Count | Cable OD | reinforcer | Fiber Jacket | Jacked Color |
| 1=G652D 2=G657A1 3=G657A2 4=50/125 5=62.5/125 6=OM3 7=OM4 X=other | S=simplex Z=zipcord Duplex Y=Round Duplex F=Flat Duplex B=Breakout D=Distribution R=Ribbon A=Armored W=Waterproof X=other | 001=1 core 002=2 cores 003=3 cores 024=24 cores XXX=other | 01= 0.9mm 02=2.0mm 03=3.0mm 04=2.9*6.0mm 05=1.9*3.1mm 06=4.2*7.6mm 07=9.0mm 08=11.2mm 09=4.0*7.0mm XX=other | 1=Kevlar 2=FRP 3=Armoured steel tape 4=Steel wire 5= Armoured steel tape & Steel wire | PR=PVC-OFNR PP=PVC-OFNP LH=LSZH PE=PE PU=TPU LN=Nylon HT=Hytrel xx=other | 01=Blue 02=Orange 03=Green 04=Brown 05=Slate , 06=White 07=Red 08=Black 09=Yellow 10=Violet 11=Rose 12=Aqua 13=12 Color XX=other |
