UL Certificate Wind Power Turbine Copper Power Cable, New Energy Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Insulation Material：Rubber
- Sheath Material：Rubber
- Wire Core Material：Red Copper Wire
- Certification：ISO, CCC, CE
Base Info
Description
0.6/1kV
Copper core ethylene propylene rubber insulated silicon rubber sheath cold resistant twisted resistant flexible cable for wind power generationFDEG-55
Copper core ethylene propylene rubber insulated silicon rubber sheath severe cold resistant twisted resistant flexible cable for wind power generation
Spec. and sizeFDEF-25
FDEF-40
FDES-25
FDES-40
FDES-55
FDGG-40
FDGG-55
FDEG-40
FDEG-55
FDEH-25
FDEH-40
FDEH-551 1.5 ~ 400 2 1.0 ~ 35 3 1.0 ~ 300 4 1.0 ~ 300 5 1.0 ~ 300 3+1 4 ~ 300 6~36 1.5 ~ 4
Copper core ethylene propylene rubber insulated silicon rubber sheath cold resistant twisted resistant flexible cable for wind power generation
Copper core ethylene propylene rubber insulated silicon rubber sheath severe cold resistant twisted resistant flexible cable for wind power generation
Spec. and sizeFDEF-25
FDEF-40
FDES-25
FDES-40
FDES-55
FDGG-40
FDGG-55
FDEG-40
FDEG-55
FDEH-25
FDEH-40
FDEH-55
Technical performance
1.The conductor shall comply with the requirements of fifth kinds of soft round stranded conductors specified in GB/T 3956-2008
2.The highest operating temperature of Conductor: ethylene propylene rubber insulation 70ºC, 90ºC; silicone rubber insulation 90ºC.
3.The finished cable shall be to withstand the normal temperature torsion test and the low temperature torsion test specified in Appendix B of GB/T 29631-2013.
4.The finished cable shall be able to withstand weight test as specified in Appendix C of GB/T 29631-2013.
5.The finished cable shall be able to withstand the low temperature bending test specified in Appendix D of GB/T 29631-2013.
