FC 12-Core Fiber Optic Jumper Wire Cable (fan-out)

Wuhan Seifree Technology Co., Ltd.
  • Application：Communication
  • Type：Single-mode Fiber
  • Connection Structure：FC-FC
  • Material Shape：Round Wire
  • Allowed Lateral Pressure：100(N,100mm)
  • Allowed Tensile Strength：<100N

Base Info

  • Model NO.：SOFC-12-FU-FU-A-09-03-C-20
  • Core：Multicore
  • Certification：RoHS, ISO9001
  • Brand：OEM
  • Sheath Material：PVC
  • Cable：12 Fiber
  • Connector Type：FC,Upc
  • Pigtail Diameter：0.9mm
  • Fiber Type：G657A
  • Fan out Length：30cm (Accept Customization)
  • Jacket Type：PVC
  • Length：200cm
  • Transport Package：Plastic Bag
  • Specification：RoHS, ISO9001
  • Trademark：seifree
  • Origin：Wuhan, Hubei
  • HS Code：85367000
  • Production Capacity：60, 00 PCS,Month

Description

CableFirst EndSecond EndFiber TypePigtail Dim.(mm)Fan Out LengthJacket TypeLength1=1FiberFU(A)=FC/UPC(APC)FU(A)=FC/UPC(APC)H=Hi 78009=Φ0.905=50cmE=PE05=50cm2=2FiberSU(A)=SC/UPC(APC)SU(A)=SC/UPC(APC)F=Flex 10602=Φ2 mm10=100cmC=PVC10=100cm4=4Fiber……D=G652D3=Φ3mm…H=LSZH……LU(A)=LC/UPC(APC)LU(A)=LC/UPC(APC)A=G657A
20=200cmA=Armored20=200cmR=RibbonX=CustomizationB=G657BX=Customization

W=Bow-type


OM1=62.5/125


OM2=50/125


OM3=50/125


OM4=50/125

Specification
ParameterUnitValueConnector/FC ST … SC LCFerrule/PCUPCAPC(Step)APC(Conical)Fiber Type/SMMMSMMMSMMMSMMMInsertion LossdB<0.25<0.20<0.25<0.20<0.30/<0.30/RepeatabilityTime>1000InterchangeabilitydB<0.10Return LossdB>45>36>50>36>60/>60/
