• Model NO.：(N) Ym (St) -J
• Material Shape：Round Wire
• Range of Application：Effective Protection Against Influence of Alternat
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Fengda
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：US $0.5-5, Meter
• Trademark：FengDa
• Origin：Tianjin, China
• HS Code：8544492100
• Production Capacity：5, 000, 000km,Year

Installation cable for effective protection against influence of alternating electromagnetic fields by means of static shield. Such shield protection is specially used in computer sector, hospitals or measuring points in industry applying measuring instruments sensitive to electromagnetic fields. These cables are also most suitable for laying in living-rooms of the people oversensitive to radiation. Possible laying on or under plaster in dry or damp areas, same as in concrete and walls. External laying is possible only if the cable is not exposed to direct sunlight or if it is laid in cable canals. Use in dangerous environment is not permitted.

Construction:

Conductor:bare copper conductor class 1 (solid) acc. to IEC 60228 / HD 383 / DIN VDE 0295Insulation:PVC compound TI1 acc. to DIN VDE 0281 part 1, concentrically stranded cores color marked acc. to HRN HD 308 S2 / DIN VDE 0293-308,  with yellow-green protective coreFiller:cores enveloped in plastic compoundScreen, electrical shield:Al-foil, contact conductor of tinned copper (1,5 mm²)Sheath:PVC compound TM1 acc. to DIN VDE 0281 part 1sheath colour:grey (RAL 7001)Temperature range: during installationi:+5 °C up to +70 °Cfixed installed:-30 °C up to +70 °Cat short circuit of max. 5 s:up to 150 °CNominal voltage:Uο/U = 300/500 VTest voltage:2000 VMinimal inner bending radius:6DBehaviour in fire:IEC 60332-1
