Fiber Optic Cable with Aluminum Tape Layer (GYTA)
DONGGUAN TW-SCIE CO., LTD.- Application：Communication
- Type：Multi-mode Fiber
- Connection Structure：SC
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：>10000N
- Core：Multicore
Base Info
- Model NO.：GYTA
- Certification：RoHS, ISO9001
- Brand：OEM
- Sheath Material：PE
- Outer Sheath Color：Black
- Outer Sheath Material：PE
- Metallic Strengthen Member：Steel Wire
- Filler：Filling Compound
- Single Armour Material：Corrugated Aluminium Tape
- Fiber Count：2-288 Core
- Brand Name of Fiber：Corning ,Yofc,Draka,Fujikura or as Your Requiremen
- Waterblocking Material：Water Blocking Tape or Filling Compound
- Installation Style：Duct, Aerial
- Loose Tube Material：PBT with Jelly
- Transport Package：Wooden Drum
- Specification：SGS ROHS REACH ISO
- Trademark：TW-SCIE
- Origin：China (Mainland) Guangdong Dongguan
- HS Code：8544700000
- Production Capacity：200km,Day
Description
Technical data:Fiber Num. Outer diameter (mm) Weight (kg/km) Min. Bending radius(mm) Tension (N) Crash loading (N/100mm) Static Dynamic Short term Long term Short term Long term 2-30 9.8 95 10 times O. D. 20 times O. D. 1500 600 1000 300 32-36 10.3 115 38-60 10.7 115 62-72 11.3 140 74-96 12.9 175 98-120 14.4 210 122-144 15.8 245 146-216 16.3 260 218-240 19.5 345 242-288 21.7 415
