• Model NO.：RG6 with F connector
• Wire Core Material：CCS or Bare Copper
• Certification：CE, ISO, RoHS
• Model：Rg59 with Stabilized Jacket
• Brand：Libo or OEM
• Braiding Coverage：65%
• Lower Attenuation：Yes
• Jacket：UV Stabilised Jacket
• Transport Package：100m,200m,305m,1000FT or According to Client′s Spe
• Specification：RG59 with connector
• Trademark：LIBO or OEM
• Origin：China
• HS Code：854420000
• Production Capacity：20000km Per Month

CATV 75 ohm RG6 Cable Indoor PVC Jacket F Connector ROSH Compliant
Quick Details:

• Flooding compound coaxial cable
• 18AWG CCS
• Clear polyethylene insulation
• Bonded alumium tape
• Tri-shield
• Jelly or flooding compound
• UL standard PVC jacket

Product description:

Dielectric core is insulating grade virgin polyethylene.Inner conductor is bare solid copper. The 1^st shield is bonded laminated aluminum tape, the second shield is 65% aluminum wire braid; jelly or flooded compound is added before outer jacket extrusion. Outer jacket is UL standard PVC.

Applications:

RG6 cable is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.

Center conductor:

18AWG copper clad steel

Nominal diameter: 0.0403"(1.02mm)±0.01(0.0004)

Dielectric:

Gas expanded polyethylene

Nominal diameter over dielectric: 0.18"(4.57mm)

Shield:

1^st shield: bonded aluminum tape.

2nd shield: 0.15 aluminum braid wire, 4ends x16 carry, pitch 25mm, 60% coverage.

3^rd shield: normal aluminum foil.

Jelly or flooded compound is added before jacket extruding.

UL standard PVC Jacket:

Nominal diameter over jacket:0.278"(7.06mm)±0.008"(0.2mm)

Messenger version: 1.3mm zinc coated (galvanized) carbon steel wire.

Packing:

Buyer's label and carton design service is available

Electrical properties:

Impedance : 75±3 ohms

Velocity of propagation: 82% nominal

Attenuation@ 68^OF(20^oC):

@Frequency MHZ

dB/100 meters(MAX.)

5

2.66

55

5.25

211

10.10

250

11.25

270

11.48

300

12.14

330

12.76

350

13.15

400

14.11

450

15.03

500

15.93

550

16.70

600

17.77

750

19.69

870

21.33

1000

22.97

Competitive Advantage:

• RG6 cable has outstanding anti-interference effectiveness and excellent transmission reliabilities.
• RG6 cable is of low cost, and it is easy to install as well.
• Libo cable was established in 1994, it is subsidiary of Libo group which is one of the 500 largest private enterprises in China.
• Libo cable has a stable workforce and engineering team, normal lead-time for 40' FCL is around 10 days.
• Libo cable is equipped with a Provincial-level Research and Development Center; we offer OEMservice as well as ODM service
