High Quality 75ohm RG6 Coaxial Cable (50ohm LMR400, RG213, RG58, RG174, 3D-FB, RG316)
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Coal Mine
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, RoHS, UL, VDE
Base Info
- Model：RG6,U
- Brand：Feiya
- Model Number：2,3 ,4 ,5 Cores, etc.
- OEM：Yes
- ODM：Yes
- Colors：Assorted Upon Request
- Operating Environment：High Frequency Transmission
- Transport Package：Submersible Pump, Heavy Duty ,Colliery
- Trademark：Fengda
- Origin：Tianjin, China
- HS Code：8544421900
Description
Basic Info.
Model RG6/U Brand Feiya Model Number 2/3 /4 /5 Cores, etc. OEM Yes ODM Yes Colors Assorted Upon Request Operating Environment High Frequency Transmission Transport Package Submersible Pump/ Heavy Duty /Colliery Trademark Fengda Origin Tianjin, China HS Code 8544421900Product Description
Features:
- The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
- H-outer sheath = halogen-free material (HM2)
- RG-Coaxial types are in accordance with US-Military specifications MIL-C-17.
- RG/U: R=Radio, G=Guide, U=Utility
- FRNC = Flame Retardant Non-Corrosive
Application:
Coaxial cables are used in high frequency transmission, especially for transmitters and receivers, computers, radio and TV transmissions. The varied mechanical, thermal and electronic properties of Coaxial cables mean that they can be used up into the GHz levels, as per cable type.
Coaxial cables
| Inner conductor diameter mm | 7 x 0,4 Tinned copper | 19 x 0,2 Tinned copper | 1 x 0,6 Steel/copper, bare | 1 x 0,6 Steel/copper, bare | 1 x 0,6 Steel/copper, bare | 7 x 0,8 Copper, bare | 7 x 0,8 Silvered copper |
| Insulation Ø mm | 7,3 PE | 2,95 PE | 3,7 PE | 3,7 PE,hollow | 3,7 PE,hollow | 7,24 E | 7,24 PE |
| Outer conductor | Braid | Braid | Braid | Braid | 2 braids | Braid | 2 braids |
| Copper, bare | Tinned copper | Copper, bare | Copper, bare | Copper, bare,Tinned copper | Copper,bare | 2xsilvered copper | |
| Outer sheath | HM2 | HM2 | HM2 | HM2 | HM2 | HM2 | HM2 |
| Min. bending radius approx. mm | 50 | 25 | 30 | 30 | 30 | 50 | 50 |
| Temperature range °C | 35 to +80 | 35 to +80 | -35 to +80 | 35 to +80 | 50 to +70 | 35 to +80 | -35 to +80 |
| Copper weight kg/km | 58,0 | 29,0 | 28,0 | 28,0 | 48,0 | 85,0 | 120,0 |
| Outer Ø approx. mm | 10,3 | 5,4 | 6,4 | 6,4 | 6,9 | 10,3 | 10,8 |
| Weight approx. kg / km | 144 | 38 | 57 | 54 | 64 | 155 | 203 |
