UL 3549 Silicone Rubber Insulated Wires / Cables
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Conductor Material：Copper
- Sheath Material：Silicone Rubber
- Insulation Material：Silicone Rubber
- Material Shape：Round Wire
Base Info
- Model NO.：UL3549
- Certification：UL
- Brand：Yuanda
- Nominal Voltage：600V
- Transport Package：Carton
- Trademark：Yuanda
- Origin：Wuxi, China
- HS Code：8544492100
- Production Capacity：100km,Day
Description
Conductor
Insulation
Shield
Sheath
Spec AWG
Section mm 2
Structure
No./D
Diameter mm
Thickness mm
Outer diameter mm
Wrapping No./D
Outer diameter mm
Thickness mm
Nominal outer diameter mm
Max outer diameter mm
28
0.0887
7/0.127
0.381
0.76
1.90
54/0.11
2.12
0.76
3.64
3.90
26
0.1407
7/0.160
0.480
0.76
2.00
57/0.11
2.22
0.76
3.74
4.04
24
0.2266
7/0.203
0.610
0.76
2.18
60/0.11
2.25
0.76
3.77
4.07
22
0.3710
39/0.110
0.800
0.76
1.95
54/0.11
2.07
0.76
3.69
3.99
20
0.5228
26/0.160
0.985
0.76
2.09
60/0.11
2.31
0.76
3.83
4.13
18
0.8244
41/0.160
1.280
0.76
2.38
67/0.11
2.60
0.76
4.12
4.45
