H07g-K Cable Rubber Insulated Single Core Wire with Increased Heat-Resistance

Henan Hongda Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Overhead, Heating, Underground
  • Conductor Material：Copper
  • Sheath Material：Rubber
  • Insulation Material：Rubber

Base Info

  • Model NO.：h07g-k
  • Material Shape：Round Wire
  • Range of Application：H05g-K,H07g-K Cables
  • Certification：ISO9001, CE, CCC, SGS
  • Brand：Hongda
  • Colour Required：Black, Red, Blue, Yellow, Green,Yellow, White, etc
  • Transport Package：100m Per Roll,Reel, or Customer Requirement
  • Specification：1.5sqm to 120sqmm
  • Trademark：Hongda, accept OEM
  • Origin：China
  • HS Code：8544492100
  • Production Capacity：40km,Day

Description

AWGNo. of Cores x Nominal Cross Sectional Area #x mm²Nominal Thickness of Insulation
mmNominal
Overall Diameter
mmNominal Copper Weight kg/KmNominal Weight kg/KmH05G-K20(16/32)1 x 0.50.62.34.81318(24/32)1 x 0.750.62.67.21617(32/32)1 x 10.62.89.622H07G-K16(30/30)1 x 1.50.83.414.42414(50/30)1 x 2.50.94.1244212(56/28)1 x 41.05.1386110(84/28)1 x 61.05.558788(80/26)1 x 101.26.8961306(128/26)1 x 161.28.41542124(200/26)1 x 251.49.92403232(280/26)1 x 351.411.43364221(400/26)1 x 501.613.24805272/0(356/24)1 x 701.615.46727263/0(485/24)1 x 951.817.29129374/0(614/24)1 x 1201.819.711521192
