CE Certified H05vvh6-F Cable High Flexible PVC Flat Cable 4X0.75mm2

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Industrial Cable
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：H05VVH6-F Cable
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemCE Certified H05VVH6-F PVC Flat Cable ConductorFine bare or tinned copper strandsInsulationPVCOuter SheathPVCCore NumberMulticores (As client's requirement)Rated Voltage 300/500 voltsTest Voltage2KVMinimum Bending Radius10 × cable ØTemperature RangeFlexing Temperature: -5ºC to +70 ºC
Static Temperature: -40ºC to +70 ºCColorOptionalCertificationCEApplicationThe cables are used for applications with medium mechanical stresses and sharp bending in one place. They are suitable for use in dry, damp and wet rooms as power and control cable, especially on hoisting equipment, handling systems, machine tools, etc.
