• Model NO.：HTS
• Approvals：Iecex Atex Eac Ce
• Transport Package：Innner Carton Master Carton
• Specification：IECEx ATEX EAC CE
• Trademark：jiahong
• Origin：Anhui Wuhu
• Production Capacity：17000PCS Per Day

Basic Info.

Model NO. HTS Approvals Iecex Atex Eac Ce Transport Package Innner Carton Master Carton Specification IECEx ATEX EAC CE Trademark jiahong Origin Anhui Wuhu Production Capacity 17000PCS Per Day

Product Description

Industry-Use Pipeline Freeze Protection PTC Heat Trace Wire

Appliance
HTS self-regulating heating cable is a parallel circuit electric heater strip.
Designed for pipe heat tracing in industrial applications,
it is configured for use in hazardous and non-hazardous locations,
including areas where corrosives may be present.
It can provide process-temperature maintenance up to 150ºC
and it can also be used for frost protection of large pipes
and freeze protection in systems having high heat loss.
Features
Energy-saving, automatically varies its power output in response to pipe temperature changes.
Easy it installation ,can be cut to any required length.
Lower installed cost than steam tracing, less maintenance expense and less downtime.
The self-regulating effect allows the cable to be overlapped without creating hot spots or burnout.
Approved for use in non-hazardous, hazardous and corrosive environments.
Jiahong provides full range of controls and accessories
Description
The output regulation of HTS series heating cables is carried out automatically along the entire
length of heating tape according to the prevailing ambient temperature.
Its self-limiting characteristics improve safety and reliability.
It will not overheat or burnout, even when overlapped upon itself.
With optional outerjacket the heating cable is resistant to watery
and inorganic chemicals and protect against abrasion and impact damage.
HTS is suitable for use in explosion-hazardous areas up to a maximally admissible work-piece temperature of +150ºC.
Jiahong provides termination, power connection, splice, tee and end seal kit will reduce
installation time and require no special skills or tools.

Why Choose Jiahong :

22 years experience made us to be the biggest manufacturer of heating cable in Asia. The only one have CE UL ETL TUV CSA certificate  in Aisa. And 6-year's supplier of homedepot ,GE ,Grainger.

Products include heating mat ,heating cable ,thermostat and self regulating heating cable , All products approved and 100% inspected.Only adopts high-quality raw materials, key materials imported from American, Japan and Germany . It made our products with excellent quality .Better than any other competitors  in China .

25-year warranty for underfloor heating system, 10-year warranty for self-regulating  heating system; Deal and solve any of your concerns at the earliest time
Besides, we have a new cable only 2mm thickness.
