• Model NO.：coaxial cable
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS
• Brand：OEM
• Conductor Size：1.02
• Braiding：32,48,64,96,112,128,144
• Transport Package：200m,300m,305m
• Specification：0.8mm Conductor
• Origin：China
• HS Code：8544200000
• Production Capacity：4000km,Month

Basic Info.

Model NO. coaxial cable Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS Brand OEM Conductor Size 1.02 Braiding 32/48/64/96/112/128/144 Transport Package 200m/300m/305m Specification 0.8mm Conductor Origin China HS Code 8544200000 Production Capacity 4000km/Month

Product Description

2019 High Transmitting Copper Conductor CCTV Cable Coaxial Cable Rg59 with Power

RG59 Siamese CCTV cable allows installers to run both the video and power to security cameras (analog CCTV, 720p and 1080p HD cameras) using a single cable run.

RG-59 coaxial cable comes in 500 and 1000 foot spools and is available in black or white colors.

The RG59 cable that CCTV Camera Pros supplies has a solid copper core and 95% copper braided shielding.

This is the best type of coax cable to use for CCTV and HD CCTV installations.


Features:

RG59 + Power Siamese Cable
Wooden Spool
Great for CCTV and security systems18 AWG Gauge (power) and 23 AWG CCA (RG59)
UV resistant PE jacket
ETL Certified
23AWG Solid Copper Conductor
3.67mm Solid PE Dielectric
128 CCA Braiding 90% coverage
PVC Jacket 6 mm


TECHNOLOGY DATA
Characteristic Impedance	75±3Ohm
Capacitance	50±1pF/m
Velocity	>85%
Shielding Effectiveness	>100db
Insulation resistance	1000M(20ºC)
Frequence (at 20ºC)	Max.Attenuation
5MHz	2.82dB/100m
55MHz	6.73dB/100m
211MHz	12.47dB/100m
350MHz	15.75dB/100m
450MHz	17.72dB/100m
500MHz	18.70dB/100m
550MHz	19.52dB/100m
750MHz	22.87dB/100m
1000MHz	26.64dB/100m
1450MHz	32.41dB/100m
1750MHz	36.04dB/100m
