Duplex and Simplex Optical Cable Cable Gjpfjv
Zhejiang Fuchunjiang Photoelectric Science Technology Co., Ltd.- Application：Communication
- Type：Multi-mode Fiber
- Connection Structure：SC
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：>10000N
Base Info
- Model NO.：Gjpfjv
- Core：Multicore
- Certification：RoHS, UL, CE, ISO9001, VDE, CCC
- Brand：OEM
- Sheath Material：PVC
- Transport Package：Wooden or as Your Request
- Specification：2km 3km
- Trademark：FCJ OPTO TECH
- Origin：China
- HS Code：854470000
- Production Capacity：30, 000, 000km,Year
Description
Bandwidth (Class A)@850 ≥500MHZ·km ≥200MHZ·km @1300 ≥1000MHZ·km ≥600MHZ·km Numerical Aperture 0.200±0.015NA 0.275±0.015NA Cable Cut-off Wavelength ≤1260nm ≤1480nm
Technical Parameters
Environmental Characteristics
Technical Parameters
| Fiber Count | Cable Diameter mm | Cable Weight Kg/km | Tensile Strength Long/Short Term N | Crush Resistance Long/Short Term N/100m | Bending Radius Static/Dynamic mm |
| 24 | 13.8±0.5 | 70 | 500/1300 | 300/1000 | 30D/15D |
| 48 | 18.0±0.5 | 150 | 500/1300 | 300/1000 | 30D/15D |
| 96 | 25.0±0.5 | 340 | 500/1300 | 300/1000 | 30D/15D |
| 120 | 31.0±1mm | 530 | 500/1300 | 300/1000 | 30D/15D |
| Transport Temperature | -20ºC~+60ºC |
| Storage Temperature | -20ºC~+60ºC |
| Installation Temperature | -5ºC~+50ºC |
| Operating Temperature | -20ºC~+60ºC |
