PMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber Manufacturer

Jiangxi Daishing POF Co., Ltd.
  • Application：Sensor, Decorative Lighting
  • Type：Single-mode Fiber
  • Material Shape：Round Wire
  • Allowed Tensile Strength：<100N
  • Certification：RoHS, UL, CE, ISO9001
  • Brand：OEM

Base Info

  • Model NO.：D series
  • Sheath Material：PE
  • Transport Package：Carton Box
  • Trademark：Dasheng
  • Origin：Jiangxi, China
  • HS Code：9001100009
  • Production Capacity：100, 000pieces,Day

Description

ParameterUnitNumerical valueFiber optic core diametermm  Φ1.o;customized accept  Φ0.25/Φ0.50/Φ0.75Fiber optic core material PMMAFinished product diametermm Φ2.2;Customized accept  Φ2.2mm-10.0mmOuter material   Antiflaming CPE,Antiflaming PE,Antiflaming PVC,Nylon PA,TPU,TPROuter color  Black;custormized accept other colorsApplication lightwavenm 650 or 530Attenuation dB/KM <180 refractionRefractive index S1Bend radius 5 X core DiameterNumerical aperture 0.5;customized accept 0.3-0.6Incident angle 60°Splice loss dB<0.5Tensile strength N≤1.0dB(0~80N)Vibration ≤1.0dB(5~50HZ,1.5mm amplitude)Working temperature°C -55°C~+85°CStorage temperature°C-55°C~+85°CQuality standard Europe ROHS,USA standard(SONET.OC-48)Japan standard(0.653) China industry standard(YD/T1447-2006)


Products model list:



product codeInner Dia (MM)Outer Fiber Dia(MM)Jacketing materials

Attenuation

(dB/KM)

N.AOperation Temp °cLength of spool(M)C2500.250.25NO jacket≤3500.5-50~8512000D5000.50.5NO jacket≤2000.5-50~856000D7500.750.75NO jacket≤2000.5-50~852700D10001.01.0NO jacket≤2000.5-50~851500D15001.51.5NO jacket≤2000.5-50~851250 D750-10.752.2 ±0.1Black PE/PVC≤2000.5-50~852500D1000-11.02.2 ±0.1Black PE/PVC≤2000.5-50~852500D1500-11.53.0 ±0.1Black PE/PVC≤2000.5-50~852500D2000-12.03.8±0.1Black PE/PVC≤2000.5-50~85350D3000-13.05.0±0.1Black PE/PVC≤2000.5-50~85150D750-30.75*33.0 ±0.1Black PVC≤1900.5-50~85900D750-70.75*73.8 ±0.1Black PE ≤1900.5-50~85100D750-120.75*124.8 ±0.1Black PE ≤1900.5-50~85100D750-250.75*256.5 ±0.1Black PE ≤1900.5-50~85100
Features:

1,Anti-aging performance with the black PVC jacket and better for illumination.
2, Light in weight, good ductility, Flexible in transmission
3, Vibration resistance, excellent flexibility
4, Good coupling, stable and reliable light transmission.
5, Low maintenance cost, safe and easy to use.




PMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber ManufacturerPMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber Manufacturer



PMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber ManufacturerPMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber Manufacturer
PMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber ManufacturerPMMA Optical Fiber Cable Buy Direct From China PMMA Optical Fiber Manufacturer

1, Are you trading company or manufacturer?
The biggest manufacturer of POF(Plastic optical fiber) and optical cable in China.
20 years experience in POF manufacturing with13 proprietary intellectual property including 5 invention patents.
Participant Makers of national standards in POF.


2, How do you shipping the goods?
About one week by courier company.
By Sea/Air as request

3, What Terms of Payment do you support?
T/T, L/C

4, Where is your location ? How can I visit there ?
Our factory is located in No. 6 Bijiashan Road, Xincheng Industrial Park, Jinggangshan City, Jiangxi Province, 343600, Pr China
Warmly welcome you to have a visit to us at your convenience.



If any questions,please feel free to contact with us..
