Single Core 630mm2 XLPE Insulation PVC Sheath Yjv Power Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station, Copper Conductor 4 Core 120mm2 XLPE Insulated Armo
- Voltage：Low and Medium Voltage Cable
- Current：DC Cable
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：IEC 60502-1
- Wire Core Material：Tinned Wire
- Certification：ISO, CCC, CE
- Model：YJV
- Brand：Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：4 Core
- Cross Section：70mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：0.6,1kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Warranty：Three Years
- Transport Package：by Sea
- Specification：copper xlpe insulated pvc sheathed 4 core 120mm2
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：5000
Description
YJV CU/XLPE/PVC
YJLV
AL/XLPE/PVCmm2 mm mm mm mm kg/km kg/km A A A A 1×4 RE 2.24 0.7 1.4 6.5 73.7 49.0 45 35 60 50 1×6 RE 2.76 0.7 1.4 7.0 95.8 58.7 55 45 70 50 1×10 CC 3.8 0.7 1.4 8.0 140.1 78.2 75 60 95 75 1×16 CC 4.8 0.7 1.4 9.0 201.8 102.8 100 80 125 100 1×25 CC 6.0 0.9 1.4 10.6 298.9 144.2 140 115 160 130 1×35 CC 7.0 0.9 1.4 11.6 396.7 180.2 175 140 190 150 1×50 CC 8.4 1.0 1.4 13.1 543.9 234.6 210 170 225 180 1×70 CC 10.0 1.1 1.4 15.0 744.7 311.6 270 215 280 225 1×95 CC 11.5 1.1 1.5 16.6 985.6 397.8 340 275 335 270 1×120 CC 13.0 1.2 1.5 18.4 1233.0 490.6 400 320 380 305 1×150 CC 14.5 1.4 1.6 20.5 1533.8 605.8 460 370 425 340 1×185 CC 16.2 1.6 1.6 22.7 1884.9 740.3 530 415 480 375 1×240 CC 18.4 1.7 1.7 25.3 2418.0 933.1 625 490 555 435 1×300 CC 20.5 1.8 1.8 27.7 2996.5 1140.4 720 565 630 495 1×400 CC 23.5 2.0 1.9 31.4 3962.3 1487.5 815 640 705 555 1×500 CC 26.5 2.2 2.0 35.0 4933.0 1839.5 855 680 765 595 1×630 CC 30.0 2.4 2.2 39.1 6188.8 2291.0 980 790 860 680
YJLV
AL/XLPE/PVC
