Nyy H07z-R Low Medium Voltage PVC/Cep/LSZH Sheathed Copper Conductor Wire Multi-Core Solid Stranded Bare Copper Flexible Electric Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Low and Medium Voltage Cable
- Voltage：Low and Medium Voltage Cable
- Insulation Material：PVC , XLPE
- Sheath Material：PVC , Cep , LSZH
- Material Shape：Round Wire
- Wire Core Material：Solid or Stranded Bare Copper
Base Info
- Model NO.：Power Cables
- Certification：ISO, CCC, CE
- Model：60227 IEC
- Brand：Feng Da
- Colour：Red,Green,Blue,Black,White,as Request
- OEM/ODM：Yes
- Flame Test：Yes
- Transport Package：Rolls or According to Customer′s Request
- Trademark：feiya
- Origin：Tianjin, China
Description
APPLICATION
Heat resistant, flame retardant cable designed for use in the switch control, relay and instrumentation panels of power switchgear and for purposes such as internal connectors in rectifier equipment, motor starters and controllers. Tri-rated cable is sometimes referred to as BS 6231 cable, H07V2-K or panel wire.
CHARACTERISTICS
Voltage Rating
(Uo/U) UL, CSA, BS 6231: 0.6/1kV
0.5mm² - 1mm²: BS EN 50525-2-31 - H05V2-K: 300/500V
1.5mm² and above*: BS EN 505-2-31 - H07V2-K: 450/750V
Temperature Rating
UL, CSA: -15°C to +105°C
BS 6231: -15°C to +90°C
Minimum Bending Radius 6 x overall diameter
CONSTRUCTION
UL Style Number 1015
Conductor Class 5 flexible copper conductor
Insulation PVC (Polyvinyl Chloride)
