UL 1330 CSA 600V Wire-Extruded FEP Insulation (Heavy Wall) Commercial Wire
B&T (Zhangzhou) Cable Co., Ltd.- Application：Lead Wire
- Conductor Material：Copper
- Cover Material：FEP
- Type：High Temperture Wire
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：UL1330
- Wire Core Material：Copper
- Certification：CE, ISO, RoHS, CCC, UL
- Model：UL3173
- Brand：Bort
- Color：Could Be Customized Color
- Rated Voltage：600V
- Sample：Normal Sample Free
- Producing Experience：10 Years
- Packing：100m,Roll, 305m,Roll,Wrap Plastic Film Packing
- Company Type：Manufacture
- Character：Environmental Protection
- Service：OEM,ODM
- Factory Management：ISO9001:2008
- Transport Package：Coil
- Specification：22AWG
- Trademark：BORT
- Origin：China
- HS Code：8544492900
- Production Capacity：5000km,Per Year
Description
Overall Diameter
(mm)Nom. Min. Nom. Tol. 10 37/0.42 3.54 2.94 0.51 0.45 3.96 ±0.15 10 105/0.254 3.54 3.00 0.51 0.45 4.02 ±0.15 12 37/0.374 5.64 2.62 0.51 0.45 3.64 ±0.15 14 19/0.361 8.96 1.85 0.51 0.45 2.90 ±0.10 16 19/0.287 14.60 1.50 0.51 0.45 2.50 ±0.10 18 19/0.235 23.20 1.18 0.51 0.45 2.20 ±0.10 20 19/0.19 36.70 0.95 0.51 0.45 1.95 ±0.10 22 19/0.15 59.40 0.76 0.51 0.45 1.75 ±0.10 24 7/0.20 94.20 0.61 0.51 0.45 1.60 ±0.10 26 7/0.16 150.00 0.48 0.51 0.45 1.50 ±0.10 28 1/0.32 227.00 0.320 0.51 0.45 1.32 ±0.10 30 1/0.254 361.00 0.254 0.51 0.45 1.26 ±0.10
(mm)
