• Model NO.：ADSS-12B1-AT-300
• Core：24
• Certification：RoHS, UL, CE, ISO9001, VDE, CCC
• Brand：Optelc
• Sheath Material：at
• Package：Wooden Case
• Transport Package：Wooden Drum
• Specification：IEEEP1222 ITU-T. G652 ITU-TG. 655
• Trademark：OPTELEC
• Origin：China
• HS Code：85447000
• Production Capacity：500km,Month




Structural ParametersCentral reinforcing member FRP  Cable dia.    2.1     mmloose tube
(fiber jelly)  external dia.  2.0     mminner sheath  thickness    0.9     mmOut sheath  thickness 1.70    mm Kelar yarn   area  8.25    mm2Standard Section area  area   124.6   mm2








Technical Parameters

Cable external dia.12.6      mmCable Weight        134      kg/kmRated tensile strength18       knMax.Allowable strength MAT7.5       knEvery day stress EDS4.6       kn
Ultimate stress
( fiber stress)(KN)11       kn
Young's modulus11.6    kn/mm2Thermal  expansion coefficient5.6    10-6/ºCCrush resistance  long time    1100   n/100mm short time     2200   n/100 mm
Min bending radiusoperation      15D     mm Installation     20D     mmTemperature range Installation      -15∽ +60ºC  transportation and operation  -40∽ +70ºCOptical fiber extra length0.5∽0.7%Outer sheath typeElectric tracking resistance AT sheathAnti-electro-corrosion measurementCable outer sheath used Northern Europe sheath type 6081,and it is well   anti-electro-corrosion.
Introduction:
Qingdao powtech Electronics Co.,Ltd is one company which in line with ADSS/OPGW cable,cable accessories for 20 years,experienced workers,advanced technology,equipments,professional after-sales service,high quality product we can supply at a favoured price than other manufacturers in the same production line.
We are ur best choice for mutual profit .
