Hot Sell Indoor Distribution Single Mode Gjsfjbv Indoor Single Mode Multi-Core Duplex Optical Fiber Cable

Zhejiang Fuchunjiang Photoelectric Science Technology Co., Ltd.
  • Application：Communication
  • Type：Single Mode or Multi Mode
  • Connection Structure：SC
  • Material Shape：Round Wire
  • Allowed Lateral Pressure：>1000(N,100mm)
  • Allowed Tensile Strength：>10000N

Base Info

  • Model NO.：GJSFJBV
  • Core：Multicore
  • Certification：RoHS, UL, CE, ISO9001, VDE, CCC
  • Brand：OEM
  • Sheath Material：TPU, LSZH,PE,PVC
  • Transport Package：Wooden Drum or as Your Request
  • Specification：1km, 2km, 3km
  • Trademark：FCJ OPTO TECH
  • Origin：China
  • HS Code：854470000
  • Production Capacity：30, 000, 000km,Year

Description

Bandwidth
(Class A)@850  ≥500MHZ·km≥500MHZ·km@1300  ≥1000MHZ·km≥600MHZ·kmNumerical Aperture   0.200±0.015NA0.275±0.015NACable Cut-off Wavelength  ≤1260nm≤1480nm

Technical Parameters
Cable TypeTight Diameter
 mm		Cable Diameter
 mm		Cable Weight
 Kg/km		Tensile Strength
Long/Short Term N		Crush
Resistance
Long/Short Term
N/100m		Bending Radius
Static/Dynamic
   mm
GJSFJBV0.62.0*4.130300/750200/100020H/10H
GJSFJBV0.62.8*5.735300/750200/100020H/10H
GJSFJBV0.93.0*6.143300/750200/100020H/10H
Storage/Operating Temperature : -20ºC to + 60ºC
