Fiber Patch Cable Management FTTH Optical Optic Fiber Cable Pigtail and Patch Cord

TOPNET (SHENZHEN) COMMUNICATION CO.,LTD
  • Application：Communication
  • Type：Single-mode Fiber
  • Connection Structure：SC
  • Material Shape：Flat Wire
  • Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
  • Allowed Tensile Strength：100N<1000N

Base Info

  • Model NO.：FTTH Drop Cable Patch Cord
  • Core：Single Core
  • Certification：RoHS, UL, CE
  • Brand：OEM
  • Sheath Material：LSZH
  • Fiber Type Sm：G652D,G657A1,G657A2,G657b3
  • Fiber Type mm：Om1, Om2, Om3, Om4, Om5
  • Transport Package：Paper Box
  • Specification：2.0*3.0mm,2.0*5.0mm
  • Trademark：Topnet
  • Origin：China
  • HS Code：8544700000
  • Production Capacity：8000km Per Month

Description

CharacteristicSM , MMConnector type FC/SC/ST/LC/MU/MT-RJ/ESCON/E2000Diameter(mm) 0.9,2.0,3.0Polishing grade SM UPCMM UPCSM APCInsertion loss Grade B≤0.15dB≤0.1dB≤0.15dBGrade C≤0.30dB≤0.30dB≤0.30dBReturn loss ≥55dB≥30dB≥65dBInterchangeability≤0.1dBRepeatability ≤0.1dBOperation temperature (ºC)-20°C ~ +70°CStorage temperature (ºC)-40°C ~ +80°CConnector 1SU: SC/UPCSA: SC/APCLU: LC/UPCLA: LC/APCFU: FC/UPCFA: FC/APCTU: ST/UPCTA: ST/APCEU: E2000/UPCEA: E2000/APC, etc.Connector 2SU: SC/UPCSA: SC/APCLU: LC/UPCLA: LC/APCFU: FC/UPCFA: FC/APCTU: ST/UPCTA: ST/APCEU: E2000/UPCEA: E2000/APC, etc.Fiber CountSI: SimplexFiber Type2D: SM G.652D (standard)7A1: SM G.657A17A2: SM G.657A2OM1: MM 62.5/125umOM2: MM 50/125umOM3: MM 50/125umOM4: MM 50/125umOM5: MM 50/125umCable Length1: 1m (standard)1.5: 1.5m2: 2m, etcCable Diameter2: 2.0mm3: 3.0mm (standard)Jacket MaterialL: LSZH

Package
Fiber Patch Cable Management FTTH Optical Optic Fiber Cable Pigtail and Patch CordFiber Patch Cable Management FTTH Optical Optic Fiber Cable Pigtail and Patch CordFiber Patch Cable Management FTTH Optical Optic Fiber Cable Pigtail and Patch Cord
