10kv Multi-Core XLPE Insulated Overhead Cable
Henan Jiapu Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Sheath Material：PVC
- Insulation Material：XLPE
Base Info
- Model NO.：JKYJ JKLYJ JKLHYJ JKLGYJ
- Material Shape：Round Wire
- Range of Application：Refractory
- Certification：ISO9001, CE, SABS
- Brand：Jiapu
- Standards：ASTM, IEC, DIN, CSA, BS...
- Transport Package：Wooden Drums or Wooden-Steel Drums
- Specification：JKYJ JKLYJ JKLHYJ JKLGYJ
- Trademark：JP
- Origin：China
- HS Code：8544601200
- Production Capacity：5000km,Month
Description
Cross Section of Conductor
(mm2)Min.Nos. of Wires for Conductor
(mm) Insulation Thickness
(mm) Average Max. O.D.per Single-core
(mm) Max.Conductor Resistance at 20ºC
(Ω/km) Min Insulated Resistance at Rated Working Temperature
(MΩ.km) Cable Tensile Breaking Force 2x10 6 1.00 6.5x13.0 3.08 0.0067 0.67 1650 2x16 6 1.20 8.0x16.0 1.91 0.0065 0.65 2512 2x25 6 1.20 9.4x18.8 1.2 0.0054 0.54 3762 2x35 6 1.40 11.0x22.0 0.868 0.0054 0.54 5177 2x50 6 1.40 12.3x24.6 0.641 0.0046 0.46 7011 2x70 12 1.40 14.1x28.2 0.443 0.004 0.4 10354 2x95 15 1.60 16.5x33.0 0.32 0.0039 0.39 13727 2x120 15 1.60 18.1x36.2 0.252 0.0035 0.35 17339 2x150 15 1.80 20.2x40.4 0.206 0.0035 0.35 21033 2x185 30 2.00 22.5x45.0 0.164 0.0035 0.35 26732 2x240 30 2.20 25.6x51.2 0.125 0.0034 0.34 34679 4x10 6 1.00 6.5x26.0 3.08 0.0067 0.67 1650 4x16 6 1.20 8.0x32.0 1.91 0.0065 0.65 2512 4x25 6 1.20 9.4x37.6 1.2 0.0054 0.54 3762 4x35 6 1.40 11.0x44.0 0.868 0.0054 0.54 5177 4x50 6 1.40 12.3x49.2 0.641 0.0046 0.46 7011 4x70 12 1.40 14.1x56.4 0.443 0.004 0.4 10354 4x95 15 1.60 16.5x66.0 0.32 0.0039 0.39 13727 4x120 15 1.60 18.1x72.4 0.252 0.0035 0.35 17339 4x150 15 1.80 20.2x80.8 0.206 0.0035 0.35 21033 4x185 30 2.00 22.5x90.0 0.164 0.0035 0.35 26732 4x240 30 2.20 25.6x102.4 0.125 0.0034 0.34 34679
