Risun First-Rate Frame PVC Shielded Alarm Cable
Hangzhou Risun Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Alarm Cable
- Conductor Material：Bc,Tc,Cu
- Sheath Material：Frame PVC
- Insulation Material：Frame PVC
Base Info
- Model NO.：Shielded Alarm Cable
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, RoHS, CPR,SGS,ETL
- Brand：Risun or OEM
- Color：According to Request
- Shield：Pet Foil,Al Foil
- Frame Retardant：Normal,Cm,Cmr
- Transport Package：305m,Pull Box, 2boxes,CTN.
- Specification：ETL, CE, RoHS, SG, ISO9001
- Trademark：Risun or OEM
- Origin：Hangzhou, China(Mainland)
- HS Code：8544491100
- Production Capacity：20000 Boxes , Mont
Description
Basic Info.
Model NO. Shielded Alarm Cable Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CE, RoHS, CPR/SGS/ETL Brand Risun or OEM Color According to Request Shield Pet Foil/Al Foil Frame Retardant Normal/Cm/Cmr Transport Package 305m/Pull Box, 2boxes/CTN. Specification ETL, CE, RoHS, SG, ISO9001 Trademark Risun or OEM Origin Hangzhou, China(Mainland) HS Code 8544491100 Production Capacity 20000 Boxes / MontProduct Description
Risun first-rate Frame pvc Shielded Alarm Cable.
A general purpose of signal and alarm cable manufactured in 4, 6, 8, 10and 12 cores configurations. Each core consists of 8/0.22mm2 tinned copper wire that is insolated and oversheathed in FRPVC. This kind of cable is ideal for using in alarm installation or where low voltage is used.
Specification:
1. Conductor: 8x0.22mm2 tinned copper or bare copper wire, can 2-40 cores.
2. Frame Retardant PVC insulation
3. Aluminum foil shielded
4. Ripcord
5. Frame Retardant PVC jacket
Features:
Conductor Material: Bc/CCS/CCA/Tc/Cu
Insulation Material: HDPE
Certification: ISO ETL CE RoHS Reach
Conductor: Solid Bare Copper
Jacket: Frame Retardant PVC
Color: To Customers' Special Requirement
Packing: Wooden Reel, Plastic Reel, and Paper Reel
Standard: 100m/roll, 200m/roll, 305m/roll, .
Origin: Hangzhou, China
| SERIAL No. | SECTION | SPEICIFICATION | OVERALL DIAM. mm | WEIGHT (KG/KM) |
| RS-AL01 | 2*0.22mm2 | 2*7/0.20 | 3 | 11 |
| RS-AL02 | 4*0.22mm2 | 4*7/0.20 | 3.5 | 18 |
| RS-AL03 | 6*0.22mm2 | 6*7/0.20 | 4.1 | 25 |
| RS-AL04 | 8*0.22mm2 | 8*7/0.20 | 4.5 | 32 |
| RS-AL05 | 10*0.22mm2 | 10*7/0.20 | 5.2 | 39 |
| RS-AL06 | 12*0.22mm2 | 12*7/0.20 | 5.4 | 46 |
| RS-AL07 | 14*0.22mm2 | 14*7/0.20 | 5.8 | 54 |
| RS-AL08 | 20*0.22mm2 | 20*7/0.20 | 6.8 | 76 |
| RS-AL09 | 30*0.22mm2 | 30*7/0.20 | 8.4 | 114 |
| RS-AL10 | 40*0.22mm2 | 40*7/0.20 | 10 | 148 |
