Nyy Type 241 51XLPE Insulated Armored PVC Sheathed Mining Rubber Mediumlowvoltage Electric Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- OEM：Available
- Core：Single Core and Multi Core
- Standard：Customized Based on Specified National Standard
- Whether It Is Environmentally Friendly：Yes
- Color：Black Red Yellow, According to Voltage Level
- Transport Package：Standard Export Packaging
Base Info
- Model NO.：Mining Cable
- Specification：1.8m * 1.8m * 1.1m
- Trademark：Fengda
- Origin：China
- HS Code：8544421900
- Production Capacity：50000000 Meter , Year
Description
1. Flexible EPR Neoprene H07RN-F Rubber Cable Products applications
Rubber Insulated Cable is suitable for connection with household appliances, electric tools and various mobile electrical equipments of rated voltage up to and including 450/750V.
2. Products standards
BS7919, CENELEC HD22.4 S4
3. Products types & names
--H05RR-F Ordinary rubber sheathed cord.
--H05RN-F Ordinary polychloroprene or other equivalent synthetic elastomer sheathed cord (1-4 cores).
--H07RN-F Heavy polychloroprene or other equivalent synthetic elastomer sheathed flexible cable.
4. Flexible EPR Neoprene H07RN-F Rubber Cable Products characteristics
--Long-term working temperature of cables: EPR insulated cables should not be higher than 65°C, EPT/EPDM insulated cables should not be higher than 90°C.
--Such cables are more flexible and easy to move electrical appliances.
5. Rubber Cable Feature:
1). Voltage: 300/750V,0.6/1kv, 6/10kv
2). Conductor: Flexible copper/Tinned copper
3). Conductor type: copper IEC60228-2004 class1,class2,class5 and 6
4). Insulation: Vulcanised Rubber/Rubber/EPR/Silicone Rubber
5). Color of insulation: Red, Yellow, Green, Light blue, White, Black, Grey, Brown, Orange, Violet, Yellow/Gree
6). Nominal cross section area: 0.5~400mm2
7). Cores: single or multi-core
8). Standard: IEC,VDE,DIN etc
9). Packaging: Iron Or Wooden Drum or according to your requirement
10). Rubber cable type: H05RR-F,H07RN-F,H07ZZ-F,H01N2-D,NSHXAFO,NSGAFOU,H07N8-F/ ,mining rubber cable.
