• Model NO.：ADSS
• Sheath Color：Black
• Installation：Aerial
• Transport Package：Wooden Drum
• Specification：SGS ROHS REACH ISO
• Trademark：TW-SCIE
• Origin：China (Mainland) Guangdong Dongguan
• HS Code：8544700000
• Production Capacity：200km,Day

Basic Info.

Model NO. ADSS Sheath Color Black Installation Aerial Transport Package Wooden Drum Specification SGS ROHS REACH ISO Trademark TW-SCIE Origin China (Mainland) Guangdong Dongguan HS Code 8544700000 Production Capacity 200km/Day

Product Description

ADSS 100M Span Aerial 24 Fiber Optical Cable

Mechanical & Environmental Characteristics

ITEM	Value
Max. Tensile Load	7000N
Max. Crush Load (Short Term)	2200N/100mm
Max Crush Load (Long Term)	1100N/100mm
UL Fire Rated	OFNR
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Sheath Material	Standard: PE          Optional: LSZH or other


ANSI/TIA/EIA-598-B Standard Fiber Color Code
Fiber Number    Fiber Color    Fiber Number   Fiber Color
  Fiber 1                 Blue               Fiber 7              Red
  Fiber 2              Orange             Fiber 8             Black
  Fiber 3               Green              Fiber 9            Yellow
  Fiber 4              Brown               Fiber 10          Violet
  Fiber 5               Slate                Fiber 11           Rose
  Fiber 6              White                Fiber 12           Aqua
Fiber 13 and higher The color code is repeated with added black stripe or dash

Recommended laying methods
Sef-support aeria
Applicable communication and LAN
Long distance communication and LAN

Structure Characters
Loose tube wifh mon-metalic strengthen member
High flexible amaid yarn
Can work at electrix field≤ 25KV/min a ling period

Properties
Smll diameter, light weight, span can reach 1500m, with a ow additionaoad to the tower; Tensile strength can reach to 90KN; Non-metallic structure, good insuater performance, thunder-proof; The equaity aramid yarn make a good stress strain performance
