CuNi2 Alloy / Low Temperature Heating Copper nickel Wire

Shanghai Tankii Alloy Material Co., Ltd.
  • Type:Bare
  • Conductor Type:Solid
  • Application:Heating
  • Conductor Material:CuNi
  • Sheath Material:PC
  • Insulation Material:Bare

Base Info

  • Model NO.:CuNi2
  • Material Shape:Round Wire
  • Range of Application:Cold-Resistant
  • Certification:ISO9001, CE, CCC, RoHS
  • Brand:TANKII
  • Serves:Small Order Accepted
  • Sample:Sample Available
  • surface:bright
  • density:8.9g,cm3;
  • standard:ASTM,GB,DIN
  • Transport Package:Packing in Coil Cartons, Pallet, Spools, Coils
  • Specification:SGS
  • Trademark:TANKII
  • Origin:China
  • HS Code:74082200
  • Production Capacity:2000 Tons,Year

Description

NiMnFeSiCuOtherROHS DirectiveCdPbHgCr2---Bal-NDNDNDND
Mechanical PropertiesMax Continuous Service Temp200ºCResisivity at 20ºC0.05±10%ohm mm2/mDensity8.9 g/cm3Thermal Conductivity100(max)Melting Point1280ºCTensile Strength,N/mm2   Annealed,Soft140~310 MpaTensile Strength,N/mm2   Cold Rolled280~620 MpaElongation(anneal)25%(min)Elongation(cold rolled)2%(min)EMF vs Cu, μV/ºC (0~100ºC)-8Micrographic StructureausteniteMagnetic PropertyNon CuNi2 Alloy / Low Temperature Heating Copper nickel Wire
