H07rn8-F/H07bq-F/H07bb-F Heavy-Duty Rubber Sheath Flexible Cable

Shanghai Aein Wire & Cable Co., Ltd.

Type：Insulated
Conductor Type：Stranded
Conductor Material：Copper
Sheath Material：Rubber
Insulation Material：Rubber
Material Shape：Round Wire

Base Info

Model NO.：H07RN8-F,H07BQ-F,H07BB-F Cable
Range of Application：Electrical Facilities
Certification：ISO9001, CE, UL, RoHS
Brand：Aein
Transport Package：Optional
Specification：Multicore
Trademark：AEIN
Origin：Shanghai
HS Code：8544492100

Description

ItemH07RN8-F/H07BQ-F/H07BB-F Heavy-duty Rubber Sheath Flexible Cable ConductorCopper wire bareInsulationSpecial rubber compound insulationOuter sheathSpecial rubber or polyster rubber compound sheathCore NumberMulticores (As client's requirement)Peak operating voltageUo/U 450/750 V Test Voltage2500 VTemperatureFlexible Installations: -30 ºC ~ + 60 ºC
Fixed Installations: -40 ºC ~ + 90 ºCColorOptionalApplicationThis cable is a heavy-duty rubber sheathed flexible cable that is widely used in dry, humid, and humid areas under moderate mechanical stress, as well as in open-air environments and agricultural facilities. It can be used in industrial equipment such as boilers, heating plates,handheld lamps, power tools, such as drills, circular saws and household tools, and mobile motors or field equipment. The cable is also suitable for fixed installation in walls and barracks. It can be used directly on equipment parts and mechanical parts, such as elevators and cranes. It can also be used for protective and fixed installation in pipelines or equipment. The water-resistant type is specially designed for connection to submersible pumps and similar equipment in fresh water at the depth of 10M and maximum water temperature of 40ºC.
