• Model NO.：RG6
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS
• Brand：OEM
• Conductor Size：1.02
• Braiding：32,48,64,96,112,128,144
• Transport Package：200m,300m,305m
• Specification：0.8mm Conductor
• Trademark：FUU
• Origin：China
• HS Code：8544200000
• Production Capacity：4000km,Month

Basic Info.

Model NO. RG6 Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS Brand OEM Conductor Size 1.02 Braiding 32/48/64/96/112/128/144 Transport Package 200m/300m/305m Specification 0.8mm Conductor Trademark FUU Origin China HS Code 8544200000 Production Capacity 4000km/Month

Product Description

RG6 Satellite Coaxial Cable 100m Black used to transmit high-frequency signals in various electronic devices, especially in radio and TV - transmitters, computers, transmitters.

We are a professional Chinese cable manufacturer in this business, our products include coaxial cable, cable, audio, video cables, control cables. For coaxial cable, RG series based CommScope standards. Enthusiasm for the choice of selling our products both at home and abroad and international markets of high-quality, competitive price and best service. Cable lines have a common fault of the mechanical damage, insulation damage, damp insulation, insulation deterioration of aging, over-voltage, cable fault such as overheating. When failure occurs, the line should be cut off the power cable fault to find the point of failure, the failure to carry out inspection and analysis, and then proceed to repair and test, the removal of the cut until after the failure to eliminate in order to restore power supply.

Semi-flexible.

Copper-clad steel conductor.

Al Foil screen.

PVC sheath.

Foam gas injected polyethylene insulation.

Ideal for digital TV.

1 Year Manufacturer's GuaranteeSuitable for TV & Satellite Signal Distribution64 x 0.12mm Copper Braiding with Aluminium Foil Shielding100m ReelInsulated & Sheathed



Type
Conductor Material	Copper
The diameter of the conductor, mm	1.02
The material of the dielectric	Foamed PE
Diameter Dielectric, mm	4.57 ± 0.15
Type of foil	Al-Tape bonded
The number of layers	2
Braid Material	AL-MG
Surface braid,%	144X0.12
Jacket wall thickness	0.76 ± 0.15
The Jacket material	PVC
Diameter of shell, mm	6.8 ± 0.2
Color	Black  or   white

TECHNOLOGY DATA
Characteristic Impedance	75±3Ohm
Capacitance	52±1pF/m
Velocity	>82%
Conductor & Dielectric To stick (kgt/m  1m/min)	2.55kgf (10.2kgf/m)
Insulation resistance	1000MOhm(20ºC)
Frequence (at 20ºC)	Max.Attenuation
5MHz	1.90dB/100m
55MHz	5.30dB/100m
211MHz	10.0dB/100m
270MHz	11.0dB/100m
300MHz	11.60dB/100m
330MHz	12.30dB/100m
400MHz	13.60dB/100m
450MHz	14.40dB/100m
550MHz	16.20dB/100m
750MHz	19.00dB/100m
870MHz	20.60dB/100m
1000MHz	21.49dB/100m
