Hot Sale GJYXFCH 1core 2core 4core Single Mode Outdoor/Indoor Steel Wire FTTH Fiber Optic/Optical Drop Cable with Anatel Certificate
Zhejiang Fuchunjiang Photoelectric Science Technology Co., Ltd.- Application：Communication
- Type：Single-mode Fiber
- Connection Structure：Can Be Customized
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
- Core：Single Core
Base Info
- Model NO.：GJYXFCH
- Certification：RoHS, UL, CE, ISO9001, VDE, CCC
- Brand：Fcj Opto Tech
- Sheath Material：Crosslinking
- Jacked Color：Blue, Orange, Green, White etc.
- Temperature Range：-20~70 Degree
- Transport Package：Carton Box
- Specification：2KM, 3KM
- Trademark：Fcj Opto Tech.
- Origin：China
- HS Code：854470000
- Production Capacity：8000km,Month
Description
Allowable minimum drawing force of optical cable (N) (kg/km) Static Dynamic Short term Long term Short term Long term 1 (2.0±0.1)x(5.4±0.1) 20 20 40 2200 1000 600 300 2 (2.0±0.1)X(5.4±0.1) 20 20 40 2200 1000 600 300 4 (2.0±0.1)X(6.4±0.1) 20 20 40 2200 1000 600 300
Order Information:
Order Information:
| Fiber Core | Fiber Type | Count | Cable OD | reinforcer | Fiber Jacket | Jacked Color |
| 1=G652D 2=G657A1 3=G657A2 4=50/125 5=62.5/125 6=OM3 7=OM4 X=other | S=simplex Z=zipcord Duplex Y=Round Duplex F=Flat Duplex B=Breakout D=Distribution R=Ribbon A=Armored W=Waterproof X=other | 001=1 core 002=2 cores 003=3 cores 024=24 cores XXX=other | 01= 0.9mm 02=2.0mm 03=3.0mm 04=2.9*6.0mm 05=1.9*3.1mm 06=4.2*7.6mm 07=9.0mm 08=11.2mm 09=4.0*7.0mm XX=other | 1=Kevlar 2=FRP 3=Armoured steel tape 4=Steel wire 5= Armoured steel tape & Steel wire | PR=PVC-OFNR PP=PVC-OFNP LH=LSZH PE=PE PU=TPU LN=Nylon HT=Hytrel xx=other | 01=Blue 02=Orange 03=Green 04=Brown 05=Slate , 06=White 07=Red 08=Black 09=Yellow 10=Violet 11=Rose 12=Aqua 13=12 Color XX=other |
