• Model NO.：FS1030
• Transport Package：Carrying Case
• Specification：IEEE1138
• Trademark：Powtech
• Origin：China
• HS Code：85389000
• Production Capacity：1000PCS,Month

Overview Product Description

Description:

FS1030 Fiber Optic Fusion Splicer adopts a brand new design. Its powerful function and pretty low insertion loss fully satisfies the requirements for fiber splicing of the backbone and FTTx. The lightweight body and exquisite design save working space. With new fiber imagery system and pure digital design, image display is more delicate and clearer. Real-time embedded operation system provides user-friendly operation interface and more useful functions; Built-in high capacity Li-on battery supports long time operation in field; Real-time match system for humidity and air pressure makes it flexibly adapt the changing environment and obtain low insertion loss after splicing in harsh environment.

Features:
· Compact and full digital design
· Light weight (2.8Kg, including battery) and small volume
· High efficiency: 8 seconds for splicing, and 30 seconds for heating
· Three splicing mode: Auto, half-auto, manual
· Automatic splicing after closing the windshield, automatic heating after closing the heating cover
· Real-time discharging correction system, and need no adjustment of the parameters
· Simultaneously view of X and Y, 304x fiber magnification
· Real-time discharge calibration system
· Long lifetime of the electrodes: 4000 times
· Support USB and VGA interface
· One button operation to finish results download or software update
· 5.7 inch high definition LCD monitor provides clearer image display
· Battery capacity displayed on screen in real-time, precisely
· Built-in high capacity Li-on battery supports 220 times splicing and heating
· Built-in super high-brightness LED, convenience for night work
· New wind-cover design, enhance the ability to prevent the dust & wind, Max. Wind velocity of 15m/s
Technical Highlights:
· HD optical image acquisition system
· HD aligner for double separate optical fibers
· High performance CMOS sensor
· Sensor pixels 640*480

Len Imaging Optical Fiber Aligning System
· Fast evaluation of fiber profile
· Precise fiber alignment
· Precise evaluation of splicing loss

Real-time Discharging Correction System
· High performance discharging electrode
· AC-DC mix discharging technique
· Current feedback and environment compensationTechnical data



General SpecificationsPower SupplyAlternating Current:100-240 50Hz/60Hz 30W, Direct current:13.5V/4.5A
Built in 11.1VLi-ion battery charger and AC adaptorBattery LifeSupport 220 times splicing and heating on one charge (3.5hours) at leastBattery LifetimeCycle life up to 300 ~ 500 times, replaceableTension Test (N)2Electrode Lifetime>4000 times, replaceableOperating Temp. (°C)-10 ~ 50Relative Humidity0 to 95% (40 °C, non-condensing)Work Altitude (m)0 ~ 5000Instrument Weight (kg)2.3 (no battery )
2.8 (including battery)Dimensions (mm)160Lx 150W x 140HCompany Profile
