• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CCC
• Brand：Yifang
• Color：Black
• Cable Marking：Printing, Embossed or Laser
• Transport Package：Wooden Drum
• Specification：CU,XLPE,PVC
• Trademark：Yifang
• Origin：China
• HS Code：8544492100
• Production Capacity：1000km Per Month

Basic Info.

Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CCC Brand Yifang Color Black Cable Marking Printing, Embossed or Laser Transport Package Wooden Drum Specification CU/XLPE/PVC Trademark Yifang Origin China HS Code 8544492100 Production Capacity 1000km Per Month

Product Description

Low Voltage Underground Power Cable1. Standard.

IEC60502-1. IEC60228.

2. Application
The PVC insulated power cable and fire resistant cable are suitable for fixed laying in power transmission and distribution lines with A.C.50Hz and voltage rating of up to or including 6KV.

3. Performance Characteristics:

3.1. The long-term permissible operation temperature of conductor shall not be higher than 70 degree.
3.2. Conductor maximum short circuit (not more than 5 seconds) temperature shall not be higher than 160 degree .
3.3. The cable is not limited by drop in level when being laid, and the environment temperature shall not be 0 degree.
3.4. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame retardance.
3.5. Light weight, perfect bending properties, installed and maintained easily and conveniently.
Voltage rating:0.6/1KV 3.6/6KV.

4. Construction.

Voltage rating:0.6/1KV 3.6/6KV.
Conductors: copper or aluminum.
Number of cable cross: one core (Single core), two cores
(Double cores), three cores, four cores (Four Equal-section-area
cores or three equal-section-area and one smaller section area
neutral core), five cores (Five equal-section-area cores or three
equal-section-area cores and two small area neutral cores). We
provide armored type and non-armored type for the cables stated
above.
Outer sheath: PVC or PE.
