Single Mode Sc/Upc 12 Color Fiber Optic Pigtail 2.0 mm
Shenzhen Shengmeida Communication Co., Ltd.- Application：Communication, Sensor, Medicine, Probe, CATV LAN
- Type：Single-mode Fiber
- Connection Structure：SC
- Material Shape：Round Wire
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：100N<1000N
Base Info
- Model NO.：SC UPC
- Core：Double Core
- Certification：RoHS
- Brand：OEM
- Sheath Material：PVC
- Color：Yellow
- Cable Diameter：0.9mm,2.0mm,3.0mm
- Transport Package：Carton
- Specification：Any length are available
- Trademark：SMD
- Origin：Shenzhen China
- HS Code：8544700000
- Production Capacity：200000,Month
Description
Parameters
Standard Fiber Cable Assemblies
Fiber Type
SM(G.652/G.657A)
MM(OM1/OM2/OM3)
Jacket Materials
LSZH/OFNR/PVC
Connector Type
SC/LC/ST/LC/MU/MTRJ/MPO/E2000
Ferrule Materials
Ceramic
Testing Wavelengths
1310±30/1550±30nm
850±30/1300±30nm
Insertion Losss(dB)
TIA/EIA-455-107
≤ 0.2dB
(PC/UPC/APC)
≤ 0.3dB
(PC/UPC)
Return Loss(dB)
TIA/EIA-455-107
≥55dB(PC/UPC)
≥65dB(APC)
≥35dB(PC/UPC)
Exchangeability
≤ 0.2dB
Cable Assemblies
Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (° C)
-10~ + 70
Storage Temperature (° C)
-40 ~ +85
Package
1unit/bag
*All values specified are with connectors.
