Negative S Type Thermocouple Compensating Wire Sc Fiberglass Jacket
Ohmalloy Material Co., Ltd.- Type:Insulated
- Conductor Type:Stranded
- Application:Thermocouple Wires
- Conductor Material:Copper,Nicu
- Sheath Material:Fiberglass
- Insulation Material:Fiberglass
Base Info
- Model NO.:S-HPF-1115
- Material Shape:Round Wire
- Range of Application:Machinery,Thermocouple,Electricity
- Certification:ISO9001, ANSI
- Brand:Ohmalloy
- Transport Package:100m,Spool, 305m,Spool, 1000FT,Spool, 1000m,Spool
- Specification:0.02-8.2mm
- Trademark:OHMALLOY
- Origin:China
- Production Capacity:500000meters Per Month
Description
2. Physical propertiesMaterial Grade K E T N J R/S Positive leg Chromel/KP Chromel/EP Copper/TP NiCrSi/NP Fe/JP Copper/SPC Negative leg Alumel/KN Constantan/EN Constantan/TN NiSiMg/NN Constantan/JN Normal available condutor size Note: We also can make the speical size as per client's requirement. SWG/AWG also is available Product &PackageEMF value Vs Pt(μV) 100ºC 200ºC 300ºC 400ºC 500ºC 600ºC RNC(SNC) -108~-148 -376~-1416 EMF value Vs Pt(μV) 700ºC 800ºC 900ºC 1000ºC 1100ºC
Thermocouple grade of conductor material
CuNi/SNC
Solid type 0.2mm 0.3mm 0.5mm 0.8mm 1.0mm 1.13mm 1.29mm 1.37mm Stranded type 0.2mm*7 0.3mm*7 0.43mm*7 0.52mm*7 0.67mm*7
