4 Pair FTP CAT6 Cable/Computer Cable/ Communication Cable/ Network Cable CAT6
Zhejiang Kuayue Cable Co., Ltd.- Application:LAN Cable, RF Cable
- Conductor Material:Copper
- Cover Material:PE
- Type:Cat 6
- Material Shape:Flat Wire
- Conductor Type:Solid
Base Info
- Model NO.:CAT6 FTP
- Wire Core Material:Bare Copper Wire
- Certification:CE, ISO, RoHS
- Model:Hanli
- Brand:Ftpcat6
- Model No:4 Pair FTP CAT6 Cable
- Transport Package:305m
- Specification:4x2x0.57cu
- Trademark:hanli
- Origin:Zhejiang
- Production Capacity:3000000m,Month
Description
Basic Info.
Model NO. CAT6 FTP Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS Model Hanli Brand Ftpcat6 Model No 4 Pair FTP CAT6 Cable Transport Package 305m Specification 4x2x0.57cu Trademark hanli Origin Zhejiang Production Capacity 3000000m/MonthProduct Description
Product Description1.Conductor :0.56BC,0.57BC or CCA
2,insulation:HDPE ID:0.1.13mm
3,Twisted pairs.
4,Shield: PET film and aluminum foil shield.
5,Deain wire: Tinned copper ,CU, CCS or CCA drain wire
6,jacket :PVC,LZSH or PE
7,Nominal diameter: 7.8±0.2mm
8,Average thickness: 0.6mm
9,Frequency: 250MHz
10,Resistance Unbalance,maximum : 4.5%
11,Mutual Capacitance :5.6 nF/100 m @ 1 kHz
12,Dielectric Test: DC 2500V/2min at 20ºC
13. Standard: international ISO/IEC 11801; USA ANSI/TIA/EIA-568B.
14,Operating temperature range: -20 to 75°C
15,305meters pull box or 500meters wooden drum
16,OEM order is welcome
Packing ways:
100m: PE protective layer, 5 roll per carton box
305m: one roll in one carton box, two carton boxes in one master carton
500m: wooden roll package, carton box as outer package
Welcome to visit our factory and get our samples.
Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.
Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
