• Model NO.：JKV, JKLV, JKLGYJ, JKY, JKLY
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Yifang
• Supply Ability：1000 Kilometer Per Week
• Transport Package：Wooden Drums or According to Your Request
• Specification：IEC Bs ASTM DIN CSA as and So on
• Trademark：Yifang
• Origin：Zhengzhou, Henan, China
• Production Capacity：500 Kilometers Per Day

ApplicationSuitable for the interconnection in controlling, protecting and measuring systemNumber of core
2~61 cores
Rated Voltage
450/750V conform to IEC 60227-2007
600/1000V conform to IEC 60502-2004
Test VoltageAC 3000V/5Min for 450/750V, AC 3500V/5Min for 600/1000V
Maximum conductor
operating temperature
90oC for XLPE insulation
70oC for PVC insulation
Core's recognition
Up to 5 core with color
Above 5 cor with number
Color of sheathBlack and customer designatedManufactured SdandardsIEC 60227-2007, IEC 60502-2004Conductor type
IEC 60228-2004 class 1, class 2 and class5
Nominal Cross-section area:0.5~10mm2
We can produce according to your need and provide technical data.
PackingCable can be supplied in any length required.

PVC, XLPE Insulation/Unshield/Unarmoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Copper tape shield/Unarmoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Braiding shield/Unarmoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Unshield/Galvanized steel tape armoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Copper tape shield/Galvanized steel tape armoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/Unshield/Galvanized steel wire armoured/PVC, PE and LOSH sheath
PVC, XLPE Insulation/ Copper tape shield/Galvanized steel wire armoured/PVC, PE and LOSH sheath
