PVC Heating Wire UL 1285

Jiangyin Senphus Electrical Material Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Heating
  • Conductor Material：Alloy
  • Sheath Material：PVC
  • Insulation Material：Rubber

Base Info

  • Model NO.：SH-PVC-10.7ohm
  • Material Shape：Round Wire
  • Range of Application：LSOH
  • Certification：ISO9001, CE, RoHS
  • Brand：Senphus
  • Temperature Rating：90-105 Degree Centigrade
  • Nominal Voltage：125V-300V
  • Structure：Conductor Insulator
  • Product Certification：UL1285 UL1080 UL1137 UL1465 UL1796 UL1471
  • Colour：White or You Choose
  • Transport Package：Carton, Pallet, Wooden Box
  • Specification：RoHS SGS
  • Trademark：SENPHUS
  • Origin：China. Jiangsu. Jiangying
  • HS Code：85168000
  • Production Capacity：500000 Meters Per Day

Description


item
performance index
instruction

insulation PVC
tensile strength
≥ 1.05kg/mmsq

UL1581
elongation
≥ 100%
minimum average thickness
≥ 0.50mm

Finished wire
hot deformation test
≤ 50%
UL standard
Spark Test
no spark-over
6.0KV/0.15sec;
conductor resistance
nominal value+10%/-5%

resistance scope

1--10000 ohm/m
O.D. of finished product
3.0+/-0.15mm
other O.D. are optional.
length per coil
100---500m
 PVC Heating Wire UL 1285
