Lifting Equipment Overhead Crane Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：Lifting cable
- Material Shape：Flat Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
Description
Application
used in rail travelling crane, trolley,conveyors,tower crane and a variety of inspection equipments,installation for self supporting wells and storage rack, suitable for power transmission, control, lighting, communications lines.
Product DescriptionFlat Series Cable is special designed for frequent motion and flexing. This cable
can be used for festoon systems, power tracks, cable tenders, cranes and hoists.
Sheath: PCP Rubber
Conductor: Superfine Soft Bare Copper which purity can reach 99.999%.
Insulation: EPR Rubber
Technical parameters
Rated voltage: ≤1.5mm2 300/500V >1.5mm2: 450V/750V
Test voltage: ≤1.5mm2 2500V >1.5mm2: 3000V
Temperature range: -20°C to +80°C
Product Features
1.Tensile and tearing resistance, stable performance
2.Good oil resistance, abrasion resistance, cold resistance and weatherability
3.in line arrangement: freedom use length less than 35m,moving speed less than1.6/S
4.plum flower arrangement:freedom use length less than 80m,moving speed is 4-10m/s
