PVC Electric Wire UL1672 Hook up Wire

B&T (Zhangzhou) Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：for General Purpose Internal Wiring of Appliance
  • Conductor Material：Copper
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：UL1672
  • Range of Application：Flame Retardant
  • Certification：ISO9001, UL, RoHS, Reach
  • Brand：B&T
  • Rated Temperature：80 ºC
  • Rated Voltage：12-14V
  • According to：UL Subject758, UL1581, C22.2
  • Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
  • Performance：for General Purpose Internal Wiring of Appliance
  • Conductor：Stranded, Tinned or Bare Copper Conductor
  • Capacity：300,000km Annual
  • Color：Could Be Customized Color
  • Delivery Time：7-15days
  • Package：Coil or Spool Packing
  • Transport Package：610feet in Roll
  • Specification：2pin 20 AWG 2 Conductors
  • Trademark：B&T
  • Origin：Xiamen, Fujian
  • HS Code：8544492100
  • Production Capacity：300, 000km

Description

Rated Temperature105ºCRated Voltage300VStandardAWGNO.of CondInsulation Thick.Outside Thick.Packingmmmmmmm/rΩ/mm287/0.1270.450.45610.00 223.75 267/0.160.450.45610.00 139.76 2411/0.160.450.45610.00 88.36 2217/0.160.450.45610.00 60.16 2021/0.1780.450.45610.00 38.58 1834/0.1780.450.45610.00 22.98 1626/0.2540.450.45610.00 15.06 1441/0.2540.450.45610.00 9.65 1265/0.2540.450.45610.00 6.07 281/0.3200.450.45610.00 227.39 261/0.4040.450.45610.00 142.79 241/0.5110.450.45610.00 89.39 221/0.6430.450.45610.00 54.30 201/0.8130.450.45610.00 33.90 181/1.0240.450.45610.00 21.40
