CE Certified H03V2V2h2-F PVC Cable Flame Retardant 300V Cable 2X1.0mm2

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Industrial Cable
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：H03V2V2H2-F Cable
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemCE Certified H03V2V2H2-F PVC Cable ConductorBare copperInsulationPVCOuter SheathPVCCore NumberMulticores (As client's requirement)Rated Voltage 300/300 voltsTest Voltage3KVMinimum Bending RadiusFlexing: 15 x Ø
Static: 4 x ØTemperature RangeFlexing Temperature: +5ºC to +90 ºC
Static Temperature: -40ºC to +90 ºCColorOptionalCertificationCEApplicationThese cables are suitable for domestic premises, kitchen, office for light service or light portable apparatuses. With their special insulation and sheath compounds these cables are adapt for  apparatus in kitchen and heating and for use in zones with high temperatures (like lighting system apparatuses) without contact with warm parts and radiations. Unsuitable for outdoor use, in industrial and agricultural buildings or non-domestic portable tools.The maximum conductor temperature in normal use:90°C.While high temperature use, skin contact must be avoided.
