6mm 8mm E type Chromel Constantan Thermocouple Bare Wire
Shanghai Tankii Alloy Material Co., Ltd.- Type：Bare
- Conductor Type：Solid
- Application：Heating
- Conductor Material：Chromel Constantan
- Sheath Material：bare
- Insulation Material：Bare
Base Info
- Model NO.：K
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, RoHS
- Brand：Tankii
- Item：6mm 8mm E type Chromel Thermocouple Bare Wir
- Surface：Bright, oxidized
- KP：Chromel thermocouple wire
- KN：Alumel thermocouple wire
- JP：Fe thermocouple wire
- JN：CuNi thermocouple wire
- TP：Copper thermocouple wire
- TN：CuNi thermocouple wire
- Transport Package：Export Package
- Specification：CE, Rohs, SGS
- Trademark：TANKII
- Origin：Shanghai
- HS Code：7505220000
- Production Capacity：5000 Tons,Year Bare Wire Thermocouple Wire 0.711mm
Description
Conductor Name
Polarity
Code
Nominal Chemical Composition /%
Ni
Cr
Cu
NiCr
Positive
EP
90
10
--
Cu-Ni(Constantan)
Negative
EN
45
--
55
Working Temperature Range
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.3, 0.5
350
450
0.8, 1.0, 1.2
450
550
1.6, 2.0
550
650
2.5
650
750
3.2
750
900
