Bare AACSR Conductor (Aluminum Alloy Galvanized Steel Wire Stranded Conductor)
YIFANG ELECTRIC GROUP INC.- Transport Package：Drum
- Specification：10mm2~1000mm2
- Trademark：Yifang cable
- Origin：Henan Zhengzhou
Base Info
- Model NO.：AACSR Condutor
- HS Code：7614100000
- Production Capacity：500ton Per Month
Description
Code nameSize Section No.of Strands
Diameter
Strands Weight Rated
Strength Calculate D.C Resistance at20°C AWG or MCM in2 mm mm kg/km kg Ω/km Dahlia 556.5 282 19*4.35 21.73 777.0 4431 0.102 Mistletoe 556.5 37*3.11 1/2.36 21.80 777.0 4495 0.102 Orchid 636 37*3.33 1/3.35 23.31 888.0 5154 0.089 Violet 715.5 37*3.35 1/4.1 24.73 1000 5791 0.079 Nasturtium 715.5 61*2.75 1/4.72 24.76 1000 5960 0.079 Arbutus 795 37*3.72 7/1.75 26.07 1110 6303 0.071 Lilac 795 61*2.90 7/2.59 26.11 1110 6501 0.071 Anemone 874.5 37*3.91 7/2.79 27.37 1222 6821 0.065 Crocus 874.5 61*3.04 7/3.35 27.36 1222 7144 0.065 Magnolia 954 37*4.08 7/3 28.55 1333 7428 0.059 Goldenrod 954 61*3.18 7/3.35 28.60 1333 7663 0.059 Bluebell 1033.5 37*4.24
19/2.29 29.71 1443 8059 0.055
Strands
Strength
